About Plan # 116-1038

About Plan # 116-1038

2690 SQUARE FEET 4 BEDROOMS 2 FULL BATH 1 HALF BATH
2 FLOOR 21' 0" WIDTH 77' 0" DEPTH 2 GARAGE BAY

Index is a classic mid-century modern plan with a twist, it's simple shape!

Each plan set includes the following:

  • Floor plans
  • Exterior elevations
  • Building sections
  • Foundation plan
  • Floor & Roof structure layouts
  • Wall section
  • Notes
  • Electrical layout (switches, outlets)
  • Unlimited license

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required.
  • Site Plan - handled locally when required.
  • Mechanical Drawings (location of heating and air equipment and ductwork) - your subcontractors handle this.
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this.
  • Energy calculations - handled locally when required.




Write Your Own Review
Submit your changes for a FREE quote.
Submit your changes for a FREE quote.

FLOOR PLANS Flip Images

Home Plan: #116-1038 Floor Plan First Story - first story Floor Plan First Story of Modern Plan #116-1038
Home Plan: #116-1038 Floor Plan First Story - first story Floor Plan First Story of Modern Plan #116-1038
Special Offer

Order a Cost-to-Build Report and get $100 off a plan priced $500 or more!

To get started, click the “Order a Cost-to-Build Report” button above; then on the next page, click “Order Now and Get $100 Coupon” for your promo code.

Additional specs and features

Summary Information

Plan #:
# 116-1038
Floors:
2
Bedrooms:
4
Full Baths:
2
Half Baths:
1

Square Footage

Heated Sq Feet:
2690
Main Floor:
1150
Upper Floor:
1540
Unfinished Sq Ft:
Garage :
464

Dimensions

Width:
21' 0"
Depth:
77' 0"
Ridge Height:
22'0"' 0"

Architectural Styles

Contemporary
Modern

Exterior Wall Material

Rock/Stone
Shakes

Roofing Type

Hip

Roofing Material

Metal

Ceiling Height

8 Foot Ceiling

Special Feature

Dining Room
Home Office
Family Room

Garage Type

Front Entry

Exterior Wall Framing

2x6

Building Lot Type

Flat Site
Narrow Lot Design

Kitchen Features

Peninsula/Eating Bar

Master Suite Features

Master Bathroom
Second Floor Master

Additional Notes from Designer

CAD files for this plan will be delivered in both DXF (AutoCad readable) and Sketchup Pro formats.

PRICING OPTIONS

For use by design professionals, this set contains all of the CAD files for your home and will be emailed to you. Comes with a license to build one home. Recommended if making major modifications to your plans.

A full set of construction drawings in digital PDF format emailed to you. Comes with a license to build one home. PDF includes copyright release to make modifications (only minor nonstructural recommended); print as many sets as you need.

ADDITIONAL INFORMATION

All sales of house plans, modifications, and other products found on this site are final. No refunds or exchanges can be given once your order has begun the fulfillment process. Please see our Policies for additional information.

All plans offered on ThePlanCollection.com are designed to conform to the local building codes when and where the original plan was drawn.

The homes as shown in photographs and renderings may differ from the actual blueprints. For more detailed information, please review the floor plan images herein carefully.
